VSS-21ProC Camera Crane Teleprompte
Professional teleprompter VSS-21ProC is built using the traditional designed and intended for use on Camera Crane.
Works with any types and sizes of the video cameras.
Uses a special mirror (Broadcast Quality Ultra clear Beamsplitter) with the main, semi-transparent layer of amalgam with 70/30 transparency / reflectance ratio and with and additional anti-reflection (AR) coating, minimizing unwanted reflections from inner side of the mirror to prevent ghosting effect.
At the core of this design of teleprompter is a Base plate - a metal platform, which consist of polished fiber carbon tubes, 3 movable mounting plates and mounting hardware for the front part of the teleprompter hood with a mirror and a monitor. The upper mounting plate is designed for mounting a camera/camcorder. The lower plate provides mount to a pedestal or a tripod. The back adjustable plate is designated for the set of counterweights as a balancing system.
The base plate provides free horizontal movement of the mounting plates, fixing them in the desired position, and provides vertical up / down movement of the tubes with the hood, mirror and the monitor, relatively to a fixed base plate for the camera with adjustable position, which allows the use of any size of the camera.
- Monitor: 21.5’, Build in image Flipper, 1000nits, SDI(optinal +USD200), HDMI, VGA, CV
- Beamsplitter: 30/70, Ultra Clear, AR coating, 450*480mm
- Materials: Carbon Fiber, Aluminum, Steel
- Weight: 7,2kg
|Size:||450x480 mm (17,7x18,9 in)|
In the box:
- Teleprompter hood with a Beamsplitter 70/30 and AR coating, 450*480mm
- Base plate with mounting brackets
- 21.5” LCD monitor with standard cables (HDMI, VGA, CV) SDI separately +USD200
- Control foot pedal
- Prompting software VSPrompter3
- Kit of screws with different sizes for mounting
- Optionally aluminum carrying case +USD200
